| LOCATION: |
| City: |
Apodaca,
Nuevo León (Monterrey) |
| Industrial Park: |
Regio Park
(Regio Parque Industrial) |
| BUILDING
AREA: |
| Total area: |
134,485 sqft |
| Production/warehouse: |
127,361
sqft |
| Office: |
7,124 sqft (two 3,562 sqft
units) |
| Expansion: |
134,484 sqft |
| BUILDING
CONFIGURATION: |
| Clear height below frame: |
24 ft |
| Column spacing: |
86.67' x 34.6' |
| Roof slope: |
6.25% |
| Roof type: |
U.S. Standing Seam |
| Roof Insulation: |
3.5" fiberglass |
| Wall type: |
0'
to roof line, precast concrete |
| Wall insulation: |
Concrete, 2" polystyrene |
| RESTROOM: |
| Men: |
140 persons |
| Women: |
140 persons |
| Office: |
80 persons |
| EXTERIOR
AREAS: |
| Dock spaces: |
6 |
| Access ramp: |
2 |
| Parking spaces: |
46 car |
| ELECTRICAL
/ ILUMINATION: |
| KVA: |
Open |
| Production/warehouse illum.: |
Open |
| Office illumination: |
100 ft candles |
| Restroom illumination: |
50 ft candles |
| Exterior illumination: |
yes, wall packs
building / 2 posts in parking area |
| A/C: |
| Office: |
yes 1 ton / 220 sqft |
| Production: |
OPTIONAL (Upon request) |
| OTHER: |
| Water storage: |
10,000
lt. |
| Garden sprinkler system: |
yes, Automatic |
| Guard house: |
yes, two 96 sqft units |
| |
For a full description of
the building's specifications please go to it's SPECIFICATIONS
PAGE.
If your company has additional equipment and
installations needs we can work with you to include them
as part of the lease. |
|
 |
